Solid Skid Steer Tire and Wheel Assemblies
When skid steer tire performance is your priority use Rhino!
For a skid loader, skid-steer loader or skidsteer.
SOLID SKS SERIES:
ADVANTAGES:
- Tires sold separately or as an assembly
- Demountable solid tires
- Can reuse the wheel
- ISO certified production
- R4 tread pattern is standard
TREAD CHARACTERISTICS:
- Disposal of mud & water
- Load capacity
- Traction ride
RECOMMENDED APPLICATIONS:
- Muddy or dirt surfaces
- Maximum machine width is needed
- Elevates the machine higher off the ground (33 x 12-20 & 36 x 14-20)
SKS Solid Tire and Wheel Assemblies |
||||||
| TIRE SIZE |
RIM (inches) |
O.D. (inches) |
S.W. (inches) |
WEIGHT (lbs) Tire only |
WEIGHT (lbs) Tire/Wheel Assembly |
CAPACITY 16MPH (lbs) |
| 31 x 10-20 | 7.5 | 30.2 | 9.1 | 155 | 200 | 4,963 |
| 33 x 12-20 | 7.5 | 32.9 | 11.8 | 200 | 310 | 8,800 |
| 36 x 14-20 | 7.5 | 36.2 | 10.8 | 284 | 375 | 10,600 |
Other sizes available upon request.
NON-DIRECTIONAL SOLID SKID STEER SERIES:
ADVANTAGES:
- Tires sold separately or as an assembly
- Demountable solid tires
- Can reuse the wheel
- ISO certified production
TREAD CHARACTERISTICS:
- Heavy duty
- Heavy load rating
- Less vibration
- Long lasting
- Thick tread design
RECOMMENDED APPLICATIONS:
- Hard surfaces, dirt, mud and turf
Non-Directional Solid Skid Steer Tire and Wheel Assemblies |
||||||
| TIRE SIZE |
RIM (inches) |
O.D. (inches) |
S.W. (inches) |
WEIGHT (lbs) Tire only |
WEIGHT (lbs) Tire/Wheel Assembly |
CAPACITY 16MPH (lbs) |
| 33 x 12-20 | 7.5 | 32.9 | 11.8 | 200 | 310 | 8,800 |
| 36 x 14-20 | 7.5 | 36.2 | 10.8 | 284 | 375 | 10,600 |
Other sizes available upon request.
